Series:
Models:
Colour:
Height:
Width:
Depth: |
|
Pronto Tema
16
RAL 9010
from 300 to 871 mm
multiples of 60 mm
from 60 to 287mm |
The Heating revolution
Tema born in 1972 and represents an extraordinary improvement in the cast iron radiators.thanks to its shape and front plate
Since its first step into market TEMA makes a revolution in the heating field. Radiators are manufactured in high quality cast iron and designed to assure a very high efficiency.
The most rational design that not only heads for the aesthetic one but to maximize the rendering of the radiators body marks the right equilibrium between radiating and convective emissions.
TEMA is protagonist into heating field, but at the same time knows how to camouflage itself with grace, its line is so much actual so moderate and elegant, so modern, that naturally adapts itself to every solution of furnishing. More than 30' years of everlasting success makes TEMA the heater more sold and copied in the world.
|
The cast iron radiators ready to install
PRONTOTEMA is supplied by enamelled white RAL 9010 at furnace 180°C using epoxy resins - a process that gives the coloured shell excellent resistance to scratching, mechanical stress, impact and abrasions, as exceptional beauty and even finish.
PRONTOTEMA comes in white RAL 9010
Available made-to-measure or in standard series 10 elements, PRONTOTEMA can be supplied tailor-made, a bigger advantage for the customer who can be supplied promptly with heaters of the desired size ranging from 1 to 20 elements. And it will be packed with shockproof protections and protected singularly with a thermoretraible packaging. On demand it is possible to have the plugs in white RAL 9010 and the paint in tans for eventual touching up. PRONTOTEMA is tested in the factory before and after the working of hubs at 10,5 bar pressure, and is suitable for working up to 7 bar. Approved by the main European institutes, it answers to norms EN 442-1/A1, CE and NF. Biancotema are tested EN 442. To guarantee for customers, on each element the marks CE, NF and the IdealClima brand are stamped on. Batteries delivering in pallet made to measure and adaptable for apartment ready for being installed in building site. |
|
Quoted drawing
Technical data
|
TYPE
|
HEIGHT
mm |
DISTANCE CENTRE
mm |
DEPTH
mm |
WIDTH
mm |
DIAM
THREAD
pollici |
WATER CONTENT
L/section |
MASS
kg/section |
UNI-EN 442
∆t 50° C
W/section |
EXPON
N° |
N°
COLUMNS |
SUR
SECT
mq
|
|
TEMA
2-871 |
874 |
813 |
60 |
60 |
1" |
0,71 |
5,00 |
81,7 |
1,300 |
2 |
0,25
|
|
TEMA
3-400 |
402 |
342 |
94 |
60 |
1" |
0,52 |
3,78 |
55,8 |
1,327 |
3 |
0,15 |
|
TEMA
3-558 |
562 |
500 |
94 |
60 |
1" |
0,73 |
4,80 |
76,2 |
1,313 |
3 |
0,21 |
|
TEMA
3-681 |
686 |
623 |
94 |
60 |
1" |
0,80 |
5,70 |
89,2 |
1,304 |
3 |
0,26 |
|
TEMA
3-871 |
875 |
813 |
94 |
60 |
1" |
1,00 |
6,80 |
109,2 |
1,289 |
3 |
0,33 |
|
TEMA
4-558 |
565 |
500 |
128 |
60 |
1" |
0,82 |
5,80 |
93,4 |
1,299 |
4 |
0,27 |
|
TEMA
4-681 |
686 |
623 |
128 |
60 |
1" |
0,97 |
7,00 |
112,1 |
1,336 |
4 |
0,33 |
|
TEMA
4-871 |
875 |
813 |
128 |
60 |
1" |
1,21 |
8,62 |
137,5 |
1,331 |
4 |
0,42 |
|
TEMA
5-558 |
561 |
500 |
162 |
60 |
1" |
1,03 |
7,35 |
113,7 |
1,311 |
5 |
0,34 |
|
TEMA
5-681 |
686 |
623 |
162 |
60 |
1" |
1,18 |
9,00 |
136,1 |
1,321 |
5 |
0,40 |
|
TEMA
5-871 |
876 |
813 |
162 |
60 |
1" |
1,43 |
11,00 |
165,8 |
1,323 |
5 |
0,50 |
|
TEMA
8-300 |
303 |
242 |
267 |
65 |
1" |
1,14 |
6,70 |
103,0 |
1,326 |
8 |
0,29 |
|
|
|
 |
