Series:
Models:
Colour:
Height:
Width:
Depth: |
|
Pronto Classic
5
RAL 9010
from 571 to 871 mm
multiples of 55 mm
from 141 to 222 mm |
The heat engages the style
From one strained of cast iron about 1870 the first cast iron heaters for domestic use are born: Projected to be not only useful but also beautiful, they become from endured important complements into furnishings.
From this in 1936 the NEOCLASSIC has been created: The soft, elegant but simple line, therefore inspired of absolute value therefore exceeding whichever fashion, produce that NEOCLASSIC is today more than ever alive and puts into effect them.
Characterized by the traditional shape in columns, that it resumes in modern key the heaters of first ' 900, NEOCLASSIC beyond 50' years is the most spread product in the heating systems around Europe.
More and more chosen also in the restructures, NEOCLASSIC represents the ideal solution in order to heat places where the atmosphere of the past is wanted to be exalted, or simply to suggest the flavour of a time also through the radiator.
The cast iron radiators ready to install
PRONTONEOCLASSIC is supplied by enamelled white RAL 9010 at furnace 180°C using epoxy resins - a process that gives the coloured shell excellent resistance to scratching, mechanical stress, impact and abrasions, as exceptional beauty and even finish.
PRONTONEOCLASSIC comes in white RAL 9010
Available made-to-measure or in standard series 10 elements, PRONTONEOCLASSIC can be supplied tailor-made, a bigger advantage for the customer who can be supplied promptly with heaters of the desired size ranging from 1 to 20 elements.
And it will be packed with shockproof protections and protected singularly with a thermoretraible packaging.
On demand it is possible to have the plugs in white RAL 9010 and the paint in tans for eventual touching up.
|
PRONTONEOCLASSIC is tested in the factory before and after the working of hubs at 10,5 bar pressure, and is suitable for working up to 7 bar.
Approved by the main European institutes, it answers to norms EN 442-1/A1, CE and NF. Prontoneoclassic are tested EN 442.
To guarantee for customers, on each element the marks CE, NF and the IdealClima brand are stamped on.
Batteries delivering in pallet made to measure and adaptable for apartment ready for being installed in building site.
Quoted drawing
 |
|
Technical data
|
TYPE
|
HEIGHT
mm |
DISTANCE CENTRE
mm |
DEPTH
mm |
WIDTH
mm |
DIAM
THREAD
pollici |
WATER CONTENT
L/section |
MASS
kg/section |
UNI-EN 442
∆t 50° C
W/section |
EXPON
N° |
N°
COLUMNS |
SUR
SECT
mq
|
|
BNC
4/571 |
571 |
500 |
141 |
55 |
1" |
0,68 |
4,65 |
79,5 |
1,294 |
4 |
0,23 |
|
BNC
4/665 |
665 |
595 |
141 |
55 |
1" |
0,74 |
5,25 |
91,1 |
1,309 |
4 |
0,27 |
|
BNC
4/871 |
871 |
801 |
141 |
55 |
1" |
0,86 |
6,89 |
115,5 |
1,345 |
4 |
0,36
|
|
BNC
6/665
|
665 |
595 |
217 |
55 |
1" |
1,07 |
8,10 |
136,0 |
1,299 |
6 |
0,40 |
|
BNC
6/871
|
871 |
800 |
217 |
55 |
1" |
1,24 |
10,80 |
170,0 |
1,319 |
6 |
0,53 |
|
|
|
 |
